EPD: Access flooring system, panels, 52 kg/m2, Concore 2500 (Tate Asia-Pacific Pty)

ConCore™ access floor panels are epoxy coated unitized shells. The shells consist of a flat steel top sheet welded to a formed steel bottom sheet. The panels are then filled with a highly controlled mixture of lightweight cement. Manufactured to exact tolerances, these non-combustible, rigid panels deliver the ultimate in design, performance, plenum integrity, service, and usability. There are seven panel grades that meet all Tate Standards and CISCA Testing Requirements, as well as Australian Standards (ConCore™ 800, ConCore™ 1000, ConCore™ 1250, ConCore™ 1500, ConCore™ 2000, ConCore™ 2500, and ConCore™ 3000) and an extensive selection of understructure supports to meet specific performance requirements. The understructure includes two different support structures for different load requirements including Bolted Stringer and Cornerlock. The table below presents the representative panel and understructure combination for each ConCore™ access floor systems

Manufacturer legal entity:

Tate Asia-Pacific Pty

Manufacturer:

Tate

Country of manufacturer:

china

Product name:

Access flooring system, panels

Commercial names:

Concore 2500

Material type:

Flooring

Material subtype:

Raised flooring systems

Environmental & technical characteristics

Global warming potential (A1-A3):

64 kg CO2e/m2

Technical specification:

52 kg/m2

Available units for calculation:

m2, kg, ton

Unique identifier (OCLID):

5f677dbe8199814dbdf7098c

Sustainability data background information

EPD number:

S-P-02049

EPD program:

Australasian EPD System

Publication year:

2020

Product category rules (PCR):

PCR 2012:01 Construction Products and Construction Services

Environmental standard:

EN15804+A1

Verification status:

Third-party verified (as per ISO 14025)

Upstream database:

ecoinvent
