EPD: Copper data cable, plenum rated, 0.0454 kg/m, 10Gain XP 6A (Superior Essex)

10Gain XP Category 6A is the first category 6A cable without a continuous shield to offer 3dB margin over Alien Crosstalk (AXT) performance requirements in ANSI/TIA-568-C.2. The uniquely designed isolation wrap contains discontinuous sections of metallized material, held in place by a polymeric layer.

Manufacturer legal entity:

Superior Essex

Manufacturer:

Superior Essex

Country of manufacturer:

kansas, USA

Product name:

Copper data cable, plenum rated

Commercial names:

10Gain XP 6A

Material type:

Installations and systems

Material subtype:

Cables

Environmental & technical characteristics

Global warming potential (A1-A3):

0.349 kg CO2e/m

Technical specification:

0.0454 kg/m

Available units for calculation:

m, kg, ton

Unique identifier (OCLID):

5fe1d80b154d00143552295f

Sustainability data background information

EPD number:

4789047039.101.1

EPD program:

UL Environment

Publication year:

2019

Product category rules (PCR):

PCR P.E.P Association. PSR Specific Rules for Wires, Cables and Accessories (2015)

Environmental standard:

EN15804+A1

Verification status:

Third-party verified (as per ISO 14025)

Upstream database:

GaBi
