EPD: Epoxy-based resin, two component, for electrical insulation, 700 ml, Part A = 1.17 g/ml, Part B = 1.50 g/ml, Mix ratio = 100:142, 1.05 kg/unit (including packaging), Electrical Insulating Resin 4 GS (3M)

The resin is SVHC-free, free of CMR-substances and does not contain isocyanates. 3M Scotchcast Electrical Insulating Resin 4 GS is classified as Low voltage Insulation Water curable (L-I-W), Low voltage outer protection Water curable (L-OP-W) and Medium voltage outer protection Water curable (M-OP-W) according to IEC 60455-3-8. The products is classified under code 34790 Other plastics in primary forms; ion exchangers in the United Nations Central products Classification (CPC) System. Depending on its application, the products covered by this Environmental products Declaration can be considered a Construction products as per the definition in European Regulation (EU) No 305/2011 laying down harmonised conditions for the marketing of Construction products. This regulation defines Construction products as any products or kit which is produced and placed on the market for incorporation in a permanent manner in Construction works or parts thereof and the performance of which has an effect on the performance of the Construction works with respect to the basic requirements for Construction works. Because Construction works are in this same regulation defined as buildings and civil engineering works 3M Scotchcast Electrical Insulating Resin 4 GS can be considered a Construction products and consequently, PCR 2012:01 v2.2 and EN 15804:2012+A1:2013 apply. It is important to note that due to the absence of so-called harmonised technical specifications, the requirements for CE marking and declaration of performance as described in the same regulation do not apply.

Manufacturer legal entity:
3M
Manufacturer:
Country of manufacturer:
belgium country flagbelgium, italy country flagitaly
Product name:
Epoxy-based resin, two component, for electrical insulation
Commercial names:
Electrical Insulating Resin 4 GS
Material type:
Coatings and pastes
Material subtype:
Resins

Environmental & technical characteristics

Global warming potential (A1-A3):
5.40 kg CO2e/unit
Technical specification:
700 ml, Part A = 1.17 g/ml, Part B = 1.50 g/ml, Mix ratio = 100:142, 1.05 kg/unit (including packaging)
Available units for calculation:
unit, kg, ton
Unique identifier (OCLID):
5d9b21998e202b501a2a7dd3

Sustainability data background information

EPD number:
S-P-00987
EPD program:
International EPD System
Publication year:
2018
Product category rules (PCR):
PCR 2012:01 Construction products and Construction services, ver. 2.2, 03/05/2017
Environmental standard:
EN15804+A1
Verification status:
Third-party verified (as per ISO 14025)
Upstream database:
GaBi
