EPD: Fluid applied membrane, 1.38 kg/L, 1.96 m2/L, 1.498 m2/kg, ASTM E 84-18, Barrithane VP (Carlisle coatings and waterproofing)

Fluid applied, vapor-permeable membrane for use as an air and water resistive barrier in above-grade wall assemblies. The product is a one part, moisture curing silane-terminated polyether (STPE). Barrithane VP is a high-solids, low VOC product. It is highly moisture resistant after cure and can be applied over damp substrates. Barrithane VP will not freeze, can be installed at sub-freezing temperatures and resists rain wash-off immediately after installation. The formulation is also fire-resistant, which allows for its use in many NFPA 285 wall assemblies. Barrithane VP is applied in single or multiple coats by roller or brush at 15-25 wet mils over exterior sheathing and 30-50 wet mils over masonry and concrete. Upon cure, Barrithane VP provides a monolithic, fully adhered membrane. 100%-solids, fluid-applied, single-component, moisture-reacted, elastomeric, coal-tar and solvent-free, modified polymer that cures to form a flexible, monolithic, waterproof membrane on vertical and horizontal surfaces. Due to the moisture-reactive and non-gassing properties of the membrane, it provides tenacious adhesion to concrete substrates above- and below-grade, preventing lateral water migration, even with moisture present in the concrete. The inherent toughness and resilience of MiraSEAL and MiraTITE enables it to bridge structural or shrinkage cracks that may develop in the substrate

Manufacturer legal entity:

Carlisle coatings and waterproofing

Manufacturer:

Carlisle

Country of manufacturer:

texas, USA

Product name:

Fluid applied membrane

Commercial names:

Barrithane VP

Material type:

Plastics, membranes and roofing

Material subtype:

Plastic membranes

Environmental & technical characteristics

Global warming potential (A1-A3):

5.18 kg CO2e/m2

Technical specification:

1.38 kg/L, 1.96 m2/L, 1.498 m2/kg, ASTM E 84-18

Available units for calculation:

m2, kg, ton

Unique identifier (OCLID):

660085a27243ef2d0e7b37f7

Sustainability data background information

EPD number:

EPD10568

EPD program:

NSF

Publication year:

2021

Product category rules (PCR):

ASTM International: Water-Resistive and Air Barriers Valid: Sept. 2022 [1]. (UNCPC 54530 and/or CSI Master Format Designations 072500, 072600 and 072700)

Environmental standard:

ISO 14040

Verification status:

Water resistant

Upstream database:

ecoinvent
