EPD: PIR High-Density (HD) roof insulation boards, polymer-bonded coated glass faced (CGF), 28.8 mm (1.13 in), 2.48 kg/m2 (5.48 lb/m2), RSI = 1 m2·K/W (5.678 ft2·°F·h/Btu), SecurShield® HD Polyiso (Versico Roofing Systems)
Polyisocyanurate (Polyiso) is a cellular closed-cell rigid foam plastic insulation. Polyiso HD roof cover boards consist of a foam core sandwiched between two facers (top and bottom). The foam core is comprised of a thermoset polymer that hardens by curing from a viscous liquid prepolymer. The rigid foam is produced through the reaction of methylene diphenylene diisocyanate (MDI) with polyester polyol. Other additives such as catalyst, surfactant, flame retardant, and blowing agent (pentane or pentane blends) are part of the formulation. Pentane is a hydrocarbon with negligible ozone depletion potential (ODP) (U.S. EPA, 2018) and low global warming potential (GWP) (U.S. EPA, 2020). For nearly 20 years, the polyiso industry has only utilized pentane or pentane blends in product formulations. Upon mixing of the components, the viscous pre-polymer is laid between the facers, and a chemical reaction cross-links polymer chains creating a rigid and durable cellular structure. The facer is comprised of polymer-bonded coated glass facer (CGF) and it plays a critical role in accommodating a continuous manufacturing process.
USA
