IFSI-EMC PURE 1KV CU Power cable with up to 1 kV operating voltage. Allowed indoors, outdoors and as a ground cable without extra protection. The Cu screen is 100% tight, has low coupling impedance and meets the EMC directive. The 3-conductor is symmetrically constructed and has a cu screen from 1.5mm². Halogen-free cable is recommended used when it is important to avoid the formation of dense smoke and corrosive gases in the event of an overheating or fire. Cables with AAL screen has a construction with an AL-foil in contact with a massive CU wire. The AL foil has an longitudinal slit and is not 100% covering (slit does not exceed 4mm). When applied to installation with highly sensitive equipment use IFSI-EMC Pure with CU screen. Product specification Conductor material Copper Conductor surface Bare Core insulation material XLPE Armoring/reinforcement material Copper, bare Screen construction Metallised foil Screen Yes Screen material Copper, bare Concentric conductor Copper Material inner sheath Halogen free polymer Material outer sheath Halogen free polymer Cable shape Round Materials kg % Copper foil, with plastic 0,02 0,47 HFFR Polyolefin 0,39 7,56 Metal - Copper 4,44 86,96 Plastic - Polyethylene 0,22 4,38 Tape - Polyester 0,03 0,63 Total 5,11 100,00
