EPD: Prefabricated insulated wall elements with polystyrene insulation, C30/37, 6000x2800x350 mm (Heidelberg Materials Precast Abetong)

The product is prefabricated insulated concrete wall elements consisting of aggregate, cement, reinforcement, insulation and the necessary cast-in-material of steel for transport and assembling. The product is almost exclusively used for facades in heated buildings. The product fulfils the requirements of SS-EN 13369:2018 Common rules for precast concrete products and SS-EN 14992:2007+A1:2012 Precast concrete products - Wall elements. Technical specifications: Concrete strength C30/37. Exposure classes up to XC4+XF3. Life length class up to L100 (100 years). Fire classes up to REI90. Typical dimensions are: Length of element 6,0 m. Height of element 2,8 m. Thickness of element 350 mm. (150 mm inner panel and 200 mm polystyrene insulation)

Manufacturer legal entity:

Heidelberg Materials Precast Abetong

Manufacturer:

Heidelberg Materials

Country of manufacturer:

sweden, OCLEPD

Product name:

Prefabricated insulated wall elements with polystyrene insulation

Material type:

Precast concrete

Material subtype:

Concrete wall elements

Environmental & technical characteristics

Global warming potential (A1-A3):

0.167 kg CO2e/kg

Technical specification:

C30/37, 6000x2800x350 mm

Available units for calculation:

kg, ton

Unique identifier (OCLID):

64e2413e6200d44a17220cf7

Sustainability data background information

EPD number:

HUB-0390

EPD program:

EPD Hub

Publication year:

2023

Product category rules (PCR):

EPD Hub Core PCR version 1.0, 1 Feb 2022 EN 16757 Product Category Rules for concrete and concrete elements

Environmental standard:

EN15804+A2

Verification status:

Third-party verified (as per ISO 14025)

Upstream database:

ecoinvent
