EPD: Sandwich panel with polyisocyanurate (PIR) foam double steel siding, U=0.24W/(m2K), 91.06mm (Total), 0.7mm (Outer sheet), 0.362mm (Liner sheet), 90mm (Insulation), 13.11kg/m2, 143.97kg/m3,, Trimapanel 90/1000 (Tata Steel Europe)

The Trimapanel family of systems from Tata Steel is an insulated, architectural wall panel system comprising of a Colorcoat pre-finished steel liner profile, a polyisocyanurate (PIR) insulation core and a microrib or flat Colorcoat pre-finished steel external weathering profile. The polyisocyanurate (PIR) insulation core uses the latest foam technology, and has a fire performance approved by Loss Prevention Certification Board (LPCB) and Factory Mutual (FM) Approvals.

Manufacturer legal entity:

Tata Steel Europe

Manufacturer:

Tata Steel

Country of manufacturer:

unitedKingdom

Product name:

Sandwich panel with polyisocyanurate (PIR) foam double steel siding

Commercial names:

Trimapanel 90/1000

Material type:

Steel and other metals

Material subtype:

Sandwich panels, metal

Environmental & technical characteristics

Global warming potential (A1-A3):

44.2 kg CO2e/m2

Technical specification:

U=0.24W/(m2K), 91.06mm (Total), 0.7mm (Outer sheet), 0.362mm (Liner sheet), 90mm (Insulation), 13.11kg/m2, 143.97kg/m3,

Available units for calculation:

m2, kg, ton, m3

Unique identifier (OCLID):

5d657d158e202b40193e57b7

Sustainability data background information

EPD number:

EPD-TS-2018-001

EPD program:

TATA Steel

Publication year:

2018

Product category rules (PCR):

EN15804+A1

Environmental standard:

EN15804+A1

Verification status:

Third-party verified (as per ISO 14025)

Upstream database:

GaBi
