EPD: Steel wall cladding system with glass mineral wool insulation, U = 0.26 W/m2K, 181.1 mm, 12.61 kg/m2, Trisobuild® Horizontal Wall Cladding (Tata Steel Europe)

Trisobuild® built-up horizontal wall systems comprise of a Colorcoat® pre-finished steel trapezoidal liner profile, a spacer system, an insulation layer and a Colorcoat® pre-finished steel external weathering profile (see Figure 1). The Trisobuild® systems incorporate a range of Tata Steel profiles and a package of Platinum® Plus pre-approved, reputable highend components that provide tested solutions from both roof and wall constructions together with solutions for fire resistance and acoustic reduction and absorption. Our dedicated and experienced building envelope technical team are available to help develop a specification for your project and assist with project specific advice to ensure that all design aspects of the chosen cladding system meet your project requirements. The wool insulation is classified as A1 to EN 13501-1 [8] and the Trisobuild® system is approved by the Loss Prevention Certification Board (LPCB) [9].

Manufacturer legal entity:

Tata Steel Europe

Manufacturer:

Tata Steel

Country of manufacturer:

unitedKingdom

Product name:

Steel wall cladding system with glass mineral wool insulation

Commercial names:

Trisobuild® Horizontal Wall Cladding

Material type:

Steel and other metals

Material subtype:

Sandwich panels, metal

Environmental & technical characteristics

Global warming potential (A1-A3):

38.2 kg CO2e/m2

Technical specification:

U = 0.26 W/m2K, 181.1 mm, 12.61 kg/m2

Available units for calculation:

m2, kg, ton, m3

Unique identifier (OCLID):

666c34de84a05a31f5a9b25b

Sustainability data background information

EPD number:

EPD-TS-2021-030

EPD program:

TATA Steel

Publication year:

2021

Product category rules (PCR):

EN15804+A1

Environmental standard:

EN15804+A1

Verification status:

Third-party verified (as per ISO 14025)

Upstream database:

GaBi
