EPD: Aluminium fencing system, 3.0 x 2.18 m, 25.94 kg/m2, load resistance up to 5.0 kN/m, SMARTIA FC10 (ALUMIL S.A.)

This is a specific EPD and covers FC10 system manufactured by ALUMIL S.A. SMARTIA FC10 is a system that is characterized by vertical lines and consequently by absolutely minimal aesthetics. At the same time, this system can successfully replace the similar linear steel constructions, without coating, corrosion and maintenance issues that accompany the latter. SMARTIA FC10 incorporates several technical characteristics and when combined with other systems, it covers a wide range of solutions and applications, while remaining aesthetically incomparable, and performing effectively at all levels. Advantages:  Particular style, not commonly met in fencings made of aluminium.  It effectively replaces the respective steel constructions.  Long fencing constructions without stability and wind‐load problems.  Smart and effective way of louvers connection ‐ especially on the top side ‐ which remains unnoticed.

Manufacturer legal entity:

ALUMIL S.A.

Manufacturer:

ALUMIL

Country of manufacturer:

greece

Product name:

Aluminium fencing system

Commercial names:

SMARTIA FC10

Material type:

Doors, windows and partitioning systems

Material subtype:

Partitioning systems (without windows)

Environmental & technical characteristics

Global warming potential (A1-A3):

217 kg CO2e/m2

Technical specification:

3.0 x 2.18 m, 25.94 kg/m2, load resistance up to 5.0 kN/m

Available units for calculation:

m2, kg, ton

Unique identifier (OCLID):

646a5a24d5e90f4cf9255fdd

Sustainability data background information

EPD number:

S‐P‐08120

EPD program:

International EPD System

Publication year:

2023

Product category rules (PCR):

PCR 2019:14 Construction products, version 1.2.5 c‐CPR‐007 Windows and doors (EN 17213:2020)

Environmental standard:

EN15804+A2

Verification status:

Third-party verified (as per ISO 14025)

Upstream database:

ecoinvent
