Manufacturer page.

Product name: NORMSTAHL OSFI42FG overhead sectional door The NORMSTAHL OSFI42FG overhead sectional door is suitable for many types of buildings, with regards to both function and appearance. High flexibility makes it possible to install this door in almost every type of building. The high light admission allows working environments with maximum lighting. The door slides up under the roof when opened, allowing free space around the door opening and leaving the door opening completely free. The door is made of insulated anodized aluminium tubular profiles, filled with sandwich panels or transparent infills, see table on next page. The frames are designed with a broken cold bridge to provide minimal thermal transmittance. This reduces energy cost (in case the space is conditioned). The frame sections have integrated finger pinch protection. There are top-, bottom- and side-seals and seals between door sections. The standard track system is made of galvanized steel. The balancing system balances the door by applying a force nearly equal to the weight of the door leaf. This allows the door leaf to be moved up and down, and to stay open in any position. The balancing system (torsion spring system or weight balancing system) supports heavy forces. In case of a spring or cable break, its counter force is lost. The door is therefore equipped with two safety devices that can block downward door movement; Spring Break Device (standard) and Cable Break Device (option, not declared in this EPD). Filling and description: • DE4D: Double hard Energy glass 4 mm Double sealed • DE6D: Double hard Energy glass 6 mm Double sealed • DH4D: Double Hard glass 4 mm Double sealed • DH6D: Double Hard glass 6 mm Double sealed The door has 4 primary parts: 1) Door leaf 2) Track set 3) Balancing system 4) Operating system/chain hoist (optional) The NORMSTAHL OSFI42FG overhead sectional door has been designed to meet operational and safety requirements in the European Directives and the standards issued by the European Standardization Committee (CEN). For the placing on the market in the EU/EFTA (excl. Switzerland), Switzerland and Turkey, the Construction Products Regulation (CPR) (EU) No 305/2011 applies. The products need a Declaration of Performance and CE marking under consideration of the Construction Products Regulation • Thermal transmittance: EN12428 2.1 W/(m²·K) Double energy glazing (valid for a DLW3600 x DLH3600 mm door) • Water penetration: EN12425 Class 3 (Door surface 4000 x 3310 mm) (no passdoor) • Air permeability: EN12426 Class 3 (4000 x 3310 mm without passdoor) • Acoustic insulation: EN ISO 10140-2 R - 24 dB (door surface 4210 x 2590 mm) The electrical unit as identified is in compliance with the following directives: 2006/42/EC Machinery Directive (MD) 2014/30/EU Electromagnetic Compatibility Directive (EMCD) 2011/65/EU RoHS 2015/863/EU RoHS Harmonized European standards, which have been applied: EN 12453:2017 Industrial, commercial and garage doors and gates – Safety in use of power operated doors – Requirements and test methods EN 60335-1 Household and similar electrical appliances - Safety -Part 1: General requirements EN 60335-2-103 Household and similar electrical appliances - Safety -Part 2: Particular requirements for drives for gates, doors and windows. EN 61000-6-2 Electromagnetic compatibility (EMC) - Part 6-2: Generic standards - Immunity for industrial environments EN 61000-6-3 Electromagnetic compatibility (EMC) — Part 6-3: Generic standards — Emission standard for residential, commercial and light-industrial environments EN ISO 13849-1 Safety of machinery — Safety-related parts of control systems — Part 1: General principles for design Disposal of the product is subject to the Waste from Electrical and Electronical Equipment (WEEE) Directive within Europe, Directive 2012/19/EU
